| Size |
50NB — 600NB |
| Material |
C.I. / C.S. / F.C.S. / SS
304/304L / SS 316/316L / Alloy
20 / Hestalloy B/C & Monel.
|
| Pressure |
150PS1 |
| Temperature |
0 Deg C - 1200 Deg C. |
| Body , Chest |
Solid One piece casting of Cast Iron Fg 260, Cast Steel Gr WCB ,CF8,CF8M. |
| Seat |
Integral to Body, Soft, Optional. |
| Gate |
AISI SS 304,316,316L,317,317L |
| Screw Spindle |
AISI SS 410,304,316. |
| Nut |
Brass |
| Yoke |
Plate type of MS . |
| Gland Follower |
Cast Iron , Cast steel , Ductile Iron ,CF8,CF8M. |
| Hand Wheel |
Cast Iron , Cast steel , Ductile Iron |
| Gland Packing |
PTFE , PTFE Impregnated |
| Ends |
Flanged ends, Screwed ends,
Socket weld ends & Butt weld
ends. |
| Port |
STANDARD [Round], Optional V Port, Diamond Port,.
|
